Place of Origin: | China |
---|---|
Brand Name: | Unionfull |
Certification: | ISO9001:2008,SGS;FDA |
Model Number: | JT8840B-50-100 |
Minimum Order Quantity: | 100 METERS |
Price: | $3.25--5.8/M2 |
Packaging Details: | 50 meters/roll,1 roll with polybag |
Delivery Time: | 7 Working Days |
Payment Terms: | T/T, L/C, Western Union, |
Supply Ability: | 30000 square meters per day |
Insulation Property: | Dielectric Constant 2.6 | Strength: | 200kg /cm2 |
---|---|---|---|
Width: | 1000mm | Weave Type: | Plain |
Materials: | Fiberglass Basic Fabric | Other Attribute:: | Non-Stick Surface |
High Light: | ptfe coated glass fibre fabric,coated fiberglass fabric |
Characteristic:
Heat resistant stability: It can be used in – 60 ℃ -260 ℃ for a long time. As per the PTFE Coated Fiberglass Cloth Tape, It can be working two hundred days in 260 ℃ during the strengthen test. Neither intensity nor weight would be reduce in the test. In the other hand, the fabric remain soft in rather low temperature instead of chap, even in -180 ℃ . It continues working for 120 hours in 350 ℃ high temperature quite well.
Excellent adhesive resistant property: especially being processed with special surface treatment, which makes the fabric unstuck, the material is free from any adhesive phenomena. Therefore, it is very easy to remove most adhesive matters. Such as paste, resin, dope ect.
Model |
Colour |
Thickness |
Weight |
Width |
|
mm |
mil |
g/m 2 |
mm |
||
JT80075A |
Beige/Fulvous |
0.075 |
3 |
145 |
1000~1260 |
JT80080A |
Beige/Fulvous |
0.08 |
3 |
155 |
1000~1260 |
JT80105A |
Beige/Fulvous |
0.105 |
4 |
210 |
1000~1260 |
JT80130A |
Beige/Fulvous |
0.13 |
5 |
270 |
1000~1500 |
JT80150A |
Beige/Fulvous |
0.15 |
6 |
315 |
1000~1500 |
JT80210A |
Fulvous/G-black |
0.21 |
8 |
430 |
1000~1500 |
Mechanical property:
It is no distortion and no shortage of the roll after bearing 200kg /cm2 a compression load, good size stability, the change of the length is below 5% . Low friction coefficient and excellent weather resistance ability.
Unique fine electric insulation property: PTFE Coated Fiberglass Cloth Tape is provided with unique insulation. Dielectric constant 2.6, tangent of dielectric wastage below 0.0025.
Excellent chemical resistance: impervious to virtually all chemical attack.
