Place of Origin: | China |
---|---|
Brand Name: | Unionfull |
Certification: | ISO9001:2008, SGS;TUV |
Model Number: | UPH-8120 |
Minimum Order Quantity: | 100 Meters |
Price: | $9.99--$12/ meter |
Packaging Details: | 50m one roll in carton, 20 rolls one pallet |
Delivery Time: | 2 weeks after receiving payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 55,000 Square Meters Per Day |
Cloth: | Woven Silica Fabric | SiO2 Content: | Above 96% |
---|---|---|---|
Area Weight: | 36oz/sq.yd | Length: | 50m One Roll |
Temperature: | 1200℃ Continuously | Weaving: | Satin Weave |
Highlight: | High Silica Cloth,High Silica Glass Fiber |
White 1.3MM High Silica Fabric 36OZ Welding Safety Blanket Flame Resistant Cloth
High silica fabric with over 96% SiO2 silicate content is a high temp heat resistant woven fabric. It is durable but flexible, chemical resistant and eco-friendly. Woven in satin weave type, this 1200gsm silica cloth is 1.3mm thick. Its heavy duty and fire resistance can withstand continuous heat and fire sparks. 1200g/m2 (36OZ) silica fabric is able to withstand heat from -50 to 1200℃ continuously. And its softening point is close to 1700℃. It is a great thermal barrier insulation materials when e-glass fiberglass cloth (used below 550℃) is not enough.
High tensile strength and abrasion resistant high silica fabric is widely used for industrial welding shield cover material for heat, sparks and hot molten spatters protection. Although this fabric is tear resistant and durable, it is still easy to fabricate (can be sewed to fire blanket or other covers).
Specification
Standard area weight of this high silica cloth is 36 oz/sq.yd.
Width of silica fabric is 91.44cm, 100cm.
Roll length is 50m (55 yards).
Items | High Silica Cloth |
SiO2 | >96% |
Area Weight | 1200g/m2 |
Thickness | 1.3mm |
Color | White |
Weave Type | Break Twill, Cross Twill |
Width | 36" |
Work Temperature | <1200°C continuously |
Features
Applications
High silica fabric is ideal for protecting people and equipment during metal cutting, stainless steel welding and welding hot works operations.
Wire, cable electrical insulation
Thermocouple&power generation insulation
Fire blankets&curtains
Welding splashes protection
Removable insulation mattress and pad
Man way insulation covers
