Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave

China Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave supplier
Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave supplier Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave supplier Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave supplier Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave supplier

Large Image :  Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave

Product Details:

Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001:2008, SGS;TUV
Model Number: JT7718B-1550

Payment & Shipping Terms:

Minimum Order Quantity: 500 METERS
Price: $5--8.5/M2
Packaging Details: 100 meters/roll,20 rolls/pallet
Delivery Time: 25 Days
Payment Terms: T/T, L/C, Western Union, O/A
Supply Ability: 30000 meters per day
Contact Now
Detailed Product Description
Specifications: High Strength Thickness: 0.25mm-0.38mm
Feature: Abrasion-Resistant, Waterproof Product Type: Carbon Fiber Fabric
Material: 100% Carbon Fiber Product: 3k Twill Carbon Fiber Cloth



Anti Static Waterproof Silver Coated Fabric Plain / Twill Weave



Carbon fibers is a key ingredient in advanced composite materials. It is the combination of high strength, high stiffness, extremely light weight , unaffected by high temperature /fuels/oils , anticorrosion, and low density that creates a product that is a higher composite material.



Carbon Fiber Fabric is made of carbon fiber by woven unidirectional, plain weaving or twill weaving style. The carbon fibers we use contain high strength-to-weight and stiffness-to-weight ratios, carbon fabrics are thermally and electrically conductive and exhibit excellent fatigue resistance. When properly engineered, carbon fabric composites can achieve the strength and stiffness of metals at significant weight savings. Carbon fabrics are compatible with various resin systems including epoxy, polyester and vinyl ester resins.





Style

Weave Pattern

FAW(g/sq.m)

Reinforcement Yarn

Fiber Count(10mm)

Thickness(mm)

Warp

Weft

End Count

Pick Count

3K-160

Plain

160

3K

3K

4

4

0.23

3K-180

Plain

180

3K

3K

4.5

4.5

0.24

3K-200

Plain/Twill

200

3K

3K

5

5

0.25

3K-P220

Plain/Twill

220

3K

3K

5.5

5.5

0.28

3K-T240

Twill/Twill

240

3K

3K

6

6

0.3

3K-P260

Plain/Twill

260

3K

3K

6.5

6.5

0.32

3K-T280

Twill

280

3K

3K

7

7

0.34



Our carbon fibre cloth / carbon fiber fabric are mostly applicable in the following areas:



1) Reinforecment/Strengthening of old buildings, bridges, tunnels etc..



2) Sports goods



3) Car parts



4) Electronic gadgets



5) Vehicles



6) Making Pre-pregs
