Unionfull® China Thermal Insulation Products Supplier | Thermal Materials - High Silica Cloth - Thermal Insulating Fiberglass Fabrics
| Place of Origin: | China |
|---|---|
| Brand Name: | Unionfull |
| Certification: | ISO9001:2008, SGS;TUV |
| Model Number: | JT8140-T30-110 |
| Minimum Order Quantity: | 50 Pieces |
| Price: | $2.25--4.85/M2 |
| Packaging Details: | 1 piece per poly bag,30 pieces per box |
| Delivery Time: | 15 Days |
| Payment Terms: | T/T, L/C, Western Union, O/A |
| Supply Ability: | 500 pieces per day |
| Raw Material: | Fiberglass Yarn | Application:: | Insulation ;Boat And Leisure |
|---|---|---|---|
| Feature: | Allowing For Use In Hand Lay Up Process To Produce Large Area Parts | Advantages: | High Mechanical Strength |
| Transverse Tensile Strength: | 35.6N/50mm | Mat Type: | Stitch Bonding Chop Mat |
| High Light: | fiberglass mat,thermal roll mat |
||
Silica Mat Insulation Felt
|
DATASHEET |
|||||
|
Part NO. |
Weight |
Thickness |
Breaking Strength(50*100mm) |
Thermal Shrikage |
|
|
g/m2 |
mm |
Wrap |
Weft |
% |
|
|
JT863 |
890 |
6.30 |
≥15 |
≥10 |
≤13 |
|
JT8127 |
2000 |
12.70 |
≥40 |
≥20 |
≤13 |
|
JT825 |
3660 |
25.00 |
≥80 |
≥40 |
≤13 |
Silica Mat Insulation Felt made by 96% silica fiberglass chopped strand through carding and needling process.Excellent insulation for sandwiching between front and rear (hot and cold side) layers of blankets & curtains.
|
Technical Datasheet |
|||||
|
Material |
Silica |
||||
|
Working temperature |
-40℃ - +1000℃ |
||||
|
Flammability |
VW-1 |
||||
|
Melting point |
+1650℃ |
||||
|
Standard Color |
Nature |
||||
|
MOQ |
300 meter each size |
||||
|
Cutting tool |
Scissors |
||||
Used extensively in the production of removable pads for welding stress relieving, furnace and oven wall gap insulation, removable pipe insulation, gas and steam turbine power generating equipment blankets, etc.
Silica Fiberglass Needle Mat is made from silica fiberglass chopped strands through carding and needling process. Fiberglass randomly distributed in 3-D structure. It has properties of small small needling hole and high porosity. It widely used as filtration and high temperature insulation material in coom, steel, nonferrous metal and chemical industry. It also used as acoustic, insulation, damping and fire resistant material in motorcycle and automobile industry.
Temperature resistance from 550 °C to 1,600 °C
Thickness: approx. 3 – 50 mm
Area weight: approx. 300 – 8,000 g/m²
Thickness: approx. 3 – 30 mm
Area weight: approx. 400 – 5,100 g/m²
