3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials

China 3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials supplier
3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials supplier 3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials supplier 3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials supplier 3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials supplier

Large Image :  3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials

Product Details:

Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001:2008, SGS;TUV
Model Number: JT8850SG-D40-100

Payment & Shipping Terms:

Minimum Order Quantity: 50 PCS
Price: Customized
Packaging Details: 1 piece per bag, 25pcs per box
Delivery Time: 7--15 working days
Payment Terms: T/T, L/C, Western Union, O/A
Supply Ability: 10000 square meters per day
Contact Now
Detailed Product Description
Materials: Thermal Insulation Material Dimensions: As Per Drawings
Density: 100-220kg/m3 Moisture Absorption Rate: Less Than 5%
Function: Removable And Reusable Inner Material: Needle Mat

3 Layers Anti Flame Thermal Insulation Covers , Heat Insulator Materials


Silicone Rubber Coated Fiberglass Fabric has been specially developed to provide a highly efficient insulation medium in a simple to fit format. The product consists of a high temperature glass fibre textile bonded to a metal foil facing to provide a flexible tape with the elastic properties required to provide a snug fit and to accommodate bends.



The materials are applied in layers according to the temperatures involved in the application, normally 3 layers are sufficient for most diesel exhaust applications. The Thermolastic system consists of two components, inner reflective insulation layers, and a choice of outer protective layer of self bonding tape depending on the temperature resistance required (see data sheet).



The matarials made of silicone coated fiberglass fabric can reduce your energy cost and make it a good business decision with a pay back that you can measure in months, not years. Weather it's an exposed steam fitting or a chemical line, it takes a lot of energy to maintain media temperature. That amount of energy can be reduced by focusing your efforts on efficient energy utilization.So that materials are your best choice and the thickness can be choose for different temperature if you like.



Total weight

1050 g/m2(Total Weight)

Thickness

0.8 mm

Color

Grey/Red

Fire resistance

Yes

Working temperature

-500C to +5000C

Coating

40g/m2 Silicone Coated On Both Sides.

Standard width

1000mm



The Energy Saving Calculation for Insulation Jacket



Rated capacity output of the heater bands

6pc.each 16KW.

2pc.each 8KW

8 heater bands in total 112KW
Operating temperature 220deg.C
Energy consumption/day without insulation 322KW/hour
With insulation 270KW/hour
Savings/day 52KW/hour=16%
Energy costs without insulation 7.90200euro
With insulation 6.62600euro
Amortization About 10 months



More of The Thermal insulation covers benefits are:



High quality removable insulation covers



For diesel, gas & steam powered engines



Fast production turnaround



Purifier and catalytic converter Insulation covers
