|Breaking Strength:||2600/2400 N/50mm||Coating Side:||2|
Fiberglass fabric is an ideal cloth that are used in demanding temperature applications throughout industrial insulation market. They are easy to fabricate and remains flexible after high temperature exposure and provides excellent protection from molten metal splash. Silicone coated fiberglass fabric has a lot of applications ranging from welding to metal cutting applications.
Details of Silicone Coated Fiberglass Fabric:
|Silicone coated fiberglass cloth|
|100000 square meters /month|
|Express Delivery, Sea Shipment, Air Shipment|
Specification of UPSE-8784D200:
Coating: Silicone rubber
Basic fabric: 3784 fiberglass fabric
Total Weight: 1050g/m2, 31oz/y2
Thickness: 0.88mm, 0.035inch
Warp Yarn: ECG37 1/2
Fill Yarn: ECG37 1/2
Temperature: up to 260℃
Four methods to weave the fabric:
a).Plain weave: it can be used in electricity insulation materials and reinforced materials in industry, because of inseparable structure, plain and clear lines.
b).Twill weave: compared with plain weave, it is of high density, high intensity, with a soft and loose structural weave. It can be used in ordinary reinforced materials, filter materials, and painting cloth.
c) Satin weave: compared with plain weave and twill weave, it is of high density,high intensity, with a soft and loose structural weave with a good texture. It is applicable for use as a higher reinforced material in machinery.
d).Gauze weave: said lattice twist weave. It can be used in spread model curtain,resin reinforced emery wheel gray cloth and lattice embed belt.
Fiberglass fabrics have flame retardant properties not found in other fabrics. The real fiberglass fabric, after the fire, because the inner skeleton of the fabric is glass fiber, it will not be deformed and will not be charred.
2.Antibacterial, moisture proof
The fabric is a natural mineral, does not provide a bacterial growth environment, bacteria can not breed, the fabric will not mold.
Glass fiber sun fabric has good thermal insulation properties that other fabrics do not have, which greatly reduces the use rate of room air conditioners, thereby saving energy.
-Gasket and for packaging, food, printing, chemical and rubber industries
-Removable insulation jackets
-Reinforced construction material
-Fabric duct-work connector
-Welding blankets,Fire curtains
Unionfull Group Ltd , an ISO9001:2008 certified manufacturer who engaged in thermal insulation materials, has grown over the years into an international supplier of high temperature and heat resistant fabrics since its establishment in 2014. We also offer customized service for specific usage with end-use products including insulation jackets, flexible connectors, fabric expansion joints.
Till now, Unionfull has successfully served hundreds of enterprises with good reputation all over the world.
