Place of Origin: | China |
---|---|
Brand Name: | Unionfull |
Certification: | CE/ISO |
Model Number: | UPSE-8732S80 |
Minimum Order Quantity: | 100 meters |
Price: | 3.86/sqm |
Packaging Details: | 1 roll with 1 carton/20 cartons/pallet |
Delivery Time: | 5 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 10000meters/day |
Color: | Customized/Grey/Green | Materials: | Fiberglass |
---|---|---|---|
Weight: | 590g/m2 | Thickness: | 0.45mm |
Width: | 1520mm | Pattern: | Satin |
Function: | Insulation | Temperature: | 550 Degrees |
High Light: | Rubber Silicone Fiberglass Fabric,1 Sided Coating Silicone Fiberglass Fabric,15oz Silicone Coated Glass Cloth |
Silicone rubber has excellent properties of thermal insulation, heat-resistance and resistance to weathering, so it can be used as coating on the fiberglass fabric for industry using. The fabric will has new properties and present high performance with silicone rubber coating, like oxygen, Non-stick, anti-corrosion, light and weathering. It has been widely used in petroleum, chemical industry, construction, airspace, machinery, metallurgy, electric insulation, and other fields.
Properties are as follows:
Life-time: 10 years(under normal environment)
Standing temperature: -70C to 280℃
Dielectric constant: 3-3.2
Breakdown voltage: 20-50KV/MM
Low shrinkage:<1%
Color: Red, gray, blue, black, orange, white,yellow or Pantone color
Advantage
Good chemical resistance
Superior Release Non-stick surface
Temperature range from -70C to +260ºC
High Intensity
Non flammable
Good weather ability
Antibacterial, moisture proof
Main Specification:
Product | Product Description | Item No. | Weight (g/m2) | Thickness (mm) |
Silicone coated fiberglass fabric. With a high temperature, fire retardant, insulation, corrosion resistance, anti-aging and other features. Silicone coated fiberglass fabric is widely used in electrical insulation, non-metallic compensator, flexible connectivity, and as a fire blanket, fire retardant curtain temperature materials, has also been used in building sealed, high-temperature corrosion conveyor belt and other fields.
|
UPSE-8732S40 | 480 | 0.43 | |
UPSE-8732S80 | 510 | 0.45 | ||
UPSE-8732D80 | 510 | 0.45 | ||
UPSE-8732D160 | 590 | 0.46 | ||
UPSE-8784S100 | 950 | 0.85 | ||
UPSE-8784D200 | 1050 | 0.88 | ||
UPSE-8788S150 | 1850 | 1.8 | ||
UPSE-8788D300 | 2000 | 1.85 | ||
UPSE-8660S100 | 760 | 0.64 | ||
UPSE-8660D200 | 860 | 0.65 |
Main Application:
1.Anti-corrosion. With excellent anti-corrosive property, silicone coated glass fabric can be used as protection coating on pipe and saving box.
2.Electrical insulation. With outstanding electrical insulation property, silicone coated glass fabric is suitable for making insulation cloth and insulating bush.
3.Non-metallic compensator. Silicone coated glass fabric can be produced as soft connecting part of pipe to avoid pipe broken caused by thermal expansion and contraction. With properties of thermal insulation, anti-corrosion, anti-aging and soft, silicone coated glass fabric is widely used in fields like oil, chemical industry, cement and energy sources.
4.Other fields. Silicone coated glass fabric can also be used as sealing material, building reinforced material, high temperature corrosion resistant conveyor belt, packing material, etc.
