High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric

China High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric supplier
High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric supplier High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric supplier High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric supplier High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric supplier

Large Image :  High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric

Product Details:

Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001,ISO2008,SGS,TUV
Model Number: UPSC-8732D160

Payment & Shipping Terms:

Minimum Order Quantity: 500m2
Price: usd1.8~2.9/m2
Packaging Details: 50 meters per roll, 20 rolls one pallet
Delivery Time: 15days after receive the payment
Payment Terms: Western Union, T/T, L/C
Supply Ability: 100000m2/Month
Contact Now
Detailed Product Description
Material: Silicone Coating Coating Sides: 2
Type: C-Glass Weave: Satin 4SH
Thickness: 0.45mm Width: 1/1.2/1.5m
Roll Length: 50m Total Weigth: 590g/m2
Basic Weight: 430g/m2 Color: Red/Black/Yellow/Orange/Blue

High-temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric



Silicone Coated Glass Fiber is a high-temp resist, anti-corrosion,high strength thermal insulation materials which is widely used in industries as welding curtain, fireproof blanket, insulation cover, reinforced material etc.



Glass fiber cloth is made of glass ball or waste glass by high temperature melting, drawing, winding, weaving and other processes.Each bundle of fiber strands consists of hundreds or even thousands of monofilaments.



The base material of the glass fiber cloth is an alkali-free glass fiber yarn, and its production process is generally made by using an enhanced boring agent. Glass fiber cloth is an indispensable insulating banding material for motors and electrical because of its excellent insulation performance and high temperature resistance.





Data:

Item Name Silicone Coated Fiberglass Fabric
Products Code UPSC-8732D160
Weight(g/m2) 430g/m2
Width 1000mm
Thickness 0.45mm
Weave Style 4H Satin
Fiber Style C-Glass
Ends Warp/Weft(cm) 17.4/14
Tensile Strength(N/MM) 270/170
Yarn type(Warp/Weft) G37 1/0 0.7Z /G37 1/0 0.7Z
Length 50m
Packing (Length/OD/Thickness) 1080x76x7mm
Others Carton





Properties:

The performance characteristics of silicone cloth are a lot:



High temperature resistance,

low thermal conductivity,

thermal shock resistance, low heat capacity;

Excellent high temperature insulation performance,

long tensile strength, long service life,

anti-melting aluminum, zinc and other non-ferrous metals;

good low temperature and high temperature strength

Non-toxic, harmless, no adverse effects on the environment;



Application:



1.In the construction industry, glass fiber cloth is widely used in wall reinforcement, exterior wall insulation, roof waterproofing, etc. It can also be applied to the reinforcement of wall materials such as cement, plastic, asphalt, marble, mosaic, etc. It is an ideal engineering material for the construction industry.



2.In the petrochemical industry, pipelines, anti-corrosion materials, storage tanks, acid, alkali, and organic solvents are applied.



3.In the transportation industry, buses, yachts, tankers, cars, etc. are used.



4.Tennis rackets, fishing rods, bows and arrows, swimming pools, bowling places, etc. in daily life are also used.





5.Because silicone cloth has fireproof effect, it is also called fireproof cloth. It has high temperature and fireproof effect and is widely used in high temperature soft connection.





Pictures:



High - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass FabricHigh - Temp 260℃ Alkali Free 0.45mm Yellow Color Silicone Coated Fiberglass Fabric
