Place of Origin: | China |
---|---|
Brand Name: | Unionfull |
Certification: | ISO9001:2008, SGS;TUV |
Model Number: | UPSE-8732D80 |
Minimum Order Quantity: | 500 Meters |
Price: | $2.85-3.40/ Square Meter |
Packaging Details: | 50 meters one roll |
Delivery Time: | 16 Working Days After Receiving Payment |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
Supply Ability: | 50,000 m2 per day |
Basic Cloth: | 430g/m2 Fiberglass Faric | Coating: | Red Silicone, 40gsm Per Side |
---|---|---|---|
Thickness: | 0.5mm | Weight: | 510g/m2 |
Width: | 1000mm, 39" | Length: | 50m One Roll |
High Light: | silicone coated glass cloth,silicone coated fiberglass cloth |
510gsm 0.5mm Red Silicone Coated Fiberglass Fabric Oil Resistant Material
Silicone coated fiberglass fabric is made of woven fiberglass cloth coated with silicone on one side or both two sides. E-glass fiberglass fabric is fire resistant, oil and chemical resistant and durable. Silicone coating also has electrical insulation property.
Basic cloth of this 0.5mm silicone coated fabric is 430g/m2 satin weaving fiberglass fabric. Total weight is 510g/m2 and 0.55mm, coating weight is 40g/m2 per side.
The basic cloth - fiberglass fabric can withstand a temperature below 550℃ continuously. Silicone coating can withstand heat below 260℃. Base on the fire resistance and other features, silicone coated fiberglass fabric are mainly used for fire/welding blanket, fabric expansion joints, hot tunnel curtains and removable thermal insulation jacket materials.
Item | Silicone Coated Fiberglass Fabric |
Material | E-glass Fiberglass |
Weave | 4H Satin |
Warp Count | 20 Ends/CM |
Weft Count | 11 Ends/CM |
Weight | 510g/m2 |
Thickness | 0.5mm |
Width | 100cm |
Servise Temperature |
Coating below 260℃ Fiberglas cloth below 550℃ |
Features:
Application:
Picture:
