Place of Origin: | China |
---|---|
Brand Name: | Unionfull |
Certification: | ISO9001,ISO2008,SGS,TUV |
Model Number: | UPSE-8732D80 |
Minimum Order Quantity: | 500m2 |
Price: | usd2.5~3.8/m2 |
Packaging Details: | 50 meters per roll, 20 rolls one pallet |
Delivery Time: | 15days after receive the payment |
Payment Terms: | Western Union, T/T, L/C |
Supply Ability: | 100000m2/Month |
Material: | Silicone Coating | Coating Sides: | 1 |
---|---|---|---|
Type: | E-Glass | Weave: | Satin 4SH |
Thickness: | 0.45mm | Width: | 1/1.2/1.5m |
Roll Length: | 50m | Total Weigth: | 510g/m2 |
Basic Weight: | 430g/m2 | Color: | Red |
High Light: | silicone coated glass cloth,silicone coated glass fabric |
Fireproof/Waterproof 40/40g Double-sided Silicone Coated Fiberglass Fabric 260℃
Silicone coated fiberglass fabrics:
Silicone cloth is a high-performance, multi-purpose composite material that is made of high-temperature, corrosion-resistant, high-strength glass fiber cloth, which is calendered or impregnated with silicone rubber.
It is an ideal material for welding blanket, fireproof curtain, thermal insulation covers.
UPSE-8732D80 has the following features:
Material: Fabric:100% E-glass fiber
Coating:Silicone Rubber
Structure:3 layers--Silicone+Glass fiber+Silicone
Coating side: Two sides
Coating Weight: 40g+40g
Total Weight: 510g
Length: 50m/roll
Width: 1m
Flammable: ≤25%
Temperature: Fiberglass cloth ≤ 550℃
Silicone coating ≤ 260℃
Type: E-glass(Alkali free)
Feature: High Temp. resist, Chemical resistant, Fire Protection,Waterproof
Properties:
1.Flame retardant performance: non-flammable
2.High temp resistant
Can as good as before under the temperature -70 ℃ to 260℃,
3.Excellent release properties
4.Non-stick,easy to wash
5.resistant to ozone, sample, light and weather aging, excellent weather ability in the field, life service up to 10 years.
6.High softness, good adhesion and no chipping
7.Good insulation
With high insulation properties, UV protection, anti-static.
Main Applications:
1.Glass fiber cloth is commonly used as a reinforcing material in composite materials, electrical insulating materials and thermal insulation materials, circuit boards and other fields of the national economy.
2.Glass fiber cloth is mainly used in industry: heat insulation, fire prevention and flame retardant. The material absorbs a large amount of heat when it is burned by flames and prevents the flame from passing through and isolating the air.
3.Anti-corrosion sector: silicone fiberglass fabric is good to be used as inner and outer anti-corrosion layer featuring excellent corrosion resistance, temperature resistance and high strength. It proves to be an ideal anti-corrosion material.
4.Non-metallic compensator: silicone fiberglass fabric could be used as pipeline flexible coupling, non-metallic compensator helps to avoid damage caused by heat expansion and cold contraction. This membrane material specially fit for use in industries of petroleum, chemical engineering, cement, iron and steel and energy sources due to its special features of temperature resistance, anti-corrosion, anti-aging, and good elasticity and toughness.
Data:
Main Specifications | |||||
Code |
Weight (g/m2) |
Thickness (mm) |
Width(m) | Color | Coating sides |
UPSE-8732S40 | 480 | 0.43 | 1/1.2/1.5 | grey,red,white | 1 |
UPSE-8732S80 | 510 | 0.45 | 1/1.2/1.5 | grey,red,white | 1 |
UPSE-8732D160 | 590 | 0.45 | 1/1.2/1.5 | grey,red,white | 2 |
UPSE-8784S40 | 890 | 0.8 | 1/1.5 | grey,red,white | 1 |
UPSE-8784D80 | 930 | 0.8 | 1/1.5 | grey,red,white | 2 |
UPSE-8784D160 | 1010 | 1.00 | 1/1.5 | grey,red,white | 2 |
UPSE-8784D200 | 1050 | 1.00 | 1/1.5 | grey,red,white | 2 |
Pictures:
