6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth

China 6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth supplier
6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth supplier 6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth supplier 6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth supplier 6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth supplier

Large Image :  6oz 30" Twill Weave Surfboard Fiberglass Cloth Fabric Surfboard Glass Fiber Cloth

Product Details:

Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001:2008, SGS;TUV
Model Number: JT8200W-20-80

Payment & Shipping Terms:

Minimum Order Quantity: 500 Meters
Price: $0.98--1.35/m2
Packaging Details: 500 meters one roll in box
Delivery Time: 20 Working Days After Payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 150000 Square Meters Per Day
Contact Now
Detailed Product Description
Cloth: 6oz Fiber Glass Cloth Weight: 6oz/yd2
Thickness: 0.2mm Width: 80cm In Stock, Customized
Color: Transparent Yarn Type: E-glass
Keyword: 6oz Fiberglass Fabric, Surfboard Fiberglass Cloth Feature: Easy Wet-Out, Fireproof

6oz Twill Weave Fiberglass Fabric Surfboard Glass Fiber Cloth



Fiberglass fabrics are woven from yarns of glass filaments. There are two types of glass fiber fabric which are used for surfboard fiberglass cloth, E-glass or S-glass fabric. The tensile strength of S-glass is about 50% higher than E-glass, meanwhile it is 25% stiffer in flex. It has higher physical strength features than E-glass but it is also more expensive. Using S-glass reduces heel dings and prolongs the life of the board. However, E-glass is the most common fiberglass fabric and is always produced in large quantities. It is a ideal high strength and economical materials.



Fiberglass fabrics with different weave, surface finish, and specification used as the reinforcement in a plastic matrix. When combined with a resin the finish fabric forms the "skin" of the surfboard.


Unionfull produces fiberglass fabric including surfboard cloth in plain or twill woven. We have twill 4oz, 6oz and 8oz e-glass fiberglass cloth in stock. So twill weave surfboard fabric will be more economical and with less delivery time. Twill weave is a pattern of diagonal parallel ribs (in contrast with satin and plain weave). Each weft yarns weave across the warp yarns in a progression of interweaves into the right or left, forming a pattern of distinct diagonal lines. The twill weave is more pliable than the plain weave and it has better drapability than plain or satin weave.

The widths of surfboard fabric which are in stock are 70cm(27.5") for 4oz, 80cm(31.5) for 6oz and 80cm for 8oz fiberglass fabric They are very common widths for surfboard manufacture which can meet most customers' needs.

Except for surfboard building, 6oz fiberglass cloth can be used for other applications. For example, it can be coated with PVC coating to be waterproofing; with silicone coating to be electrical insulation or abrasion resistance. It is also a suitable material for septic tank, pipeline repair, removable insulation cover and fire blankets production. Now it is classified as a series for sport euipments building: 4oz, 6oz, 8oz, 7628 and other light weight fiberglass fabrics, which are always used to produce snowboard, surfboard and skimboard.



Total Weight 6oz/yd2, 200g/m2
Thickness 0.2mm
Yarn Type E-glass
Weave Type Plain, (Twill in stock)
Width In Stock 80cm, 31.5"
Common Roll Length 100m/roll



Features:


  1. Different surface finish meet different applications
  2. High strength, tear resistance
  3. Durable, abrasion resistance
  4. Easily wet out, can be combined with most resins
  5. Dimensional stability, will not stretch or shrink
  6. Clear white color, transparent
  7. Fire and heat resistance
  8. Customized specification









Other surfboard fiber glass cloth:


Specifications Weight(g/m2) Thickness(mm) Width
4oz 125 0.12 70cm in stock
6oz 203 0.18 80cm in stock
8oz 220 0.19 80cm in stock
7628 200g 0.2 100cm common
