Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth

China Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth supplier
Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth supplier Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth supplier Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth supplier Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth supplier

Large Image :  Fireproof Fiberglass Fabric 3732 0.4mm Satin Cross Twill E Glass Fibre Cloth

Product Details:

Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001:2008, SGS
Model Number: JT8430W-40-100

Payment & Shipping Terms:

Minimum Order Quantity: 500 Meters
Price: $1.4--$1.55/Square Meter
Packaging Details: 50m/roll in poly bag
Delivery Time: 30 Days after the payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 100000 square meters per day
Contact Now
Detailed Product Description
Style: 3732 Fiberglass Cloth Weight: 430gsm
Thickness: 0.4mm Weave: Satin/Cross Twill
Yarn Type: E-glass Feature: Fireproof, Heavy Duty, High Strength
Application: Fire Blanket, Coated Fabric, Welding Keyword: 3732 Fiberglass Fabric Cloth



3732 0.4mm Satin Cross Twill E Glass Glass Fiber Cloth Fiberglass Fabric



3732 fiber glass cloth is a kind of industrial fabric which is 430gsm and 0.4mm thick. It is Satin weave fabric, also called cross twil or break twill weave. Compared with the plain, satin weave is with higher density and it is a soft and loose structural weave.



3732 fiberglass cloth can withstand 550°C(about 1022°F). It is always used in applications including thermal Insulation shields, welding protection, stress relieving, removable insulation covers(with silicone coating), fire blankets and curtains, fireproof bags and fabric air ducts. In order to meet some special purpose or to increase some peculiarities, always coat this fabric in various ways like waterproof PTFE/PVC coating, reflective aluminium foil laminating, Silicone/PU coating and other heat treating.



Items 3732
Weave Satin/Cross Twill
Yarn (tex) Warp
Weft
G37 1/0 0.7Z
G37 1/0 0.7Z
Thickness 0.43mm
Weight 430g/m²
Thread Count Warp
Weft
19.6/cm
11.5/cm
Tensile Strength Warp
Weft
6000N/5cm
4500N/5cm
L.O.I% 0.5
Working Temperature 550°C





Properties:



  1. Chemical corrosion resistance.
  2. Light weight
  3. High strength in both warp and weft direction;
  4. Fire resistance
  5. Electrical insulation properties
  6. Good soak and bonding with varieties of matrix resin, can be coated by Silicone/PTFE/PVC



Appplications:



  • Fire Blanket/Fire curtains
  • Welding pads/blanket
  • Pipe/flange protection cover
  • Safety cloth and apron
  • Fire fighting equipments
  • Valve thermal insulation jacket/exhaust blanket











Other Common Used Fiberglass Fabric:



Model

Density

(per cm)

Weight

(g/m2)

Thickness

(mm)

Weave type

Size

(m)

7628 18/12 200 0.2 Plain 1.27*1000m
3784 18/12 840 0.8 8HS Satin 1m*50m
3785 15/15 1050 1 8HS Satin 1m*50m
3786 17/11 1300 1.3 8HS Satin 1m*50m
3788 18/13 1600 1.6 8HS Satin 1m*50m





Glass fiber is an engineerig material, which has the excellent properties such as anti-burns, anti-corrosion, heat-resistance, minimum elongated shrinkage, high density.



This new material has already covered many field such as electric appliance, electronic insulation, transportation, chemical engineering, architectural engineering, heat insulation, sound absorption, fire protection and environmental application.
