Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth

China Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth supplier
Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth supplier Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth supplier Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth supplier Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth supplier

Large Image :  Transparent White 4oz Surfboard Fiberglass Cloth 6522 Surfboard Glass Fiber Cloth

Product Details:

Place of Origin: China
Brand Name: Unionfull
Certification: ISO9001:2008, SGS
Model Number: JT8120W-12-70

Payment & Shipping Terms:

Minimum Order Quantity: 500 Meters
Price: $0.95--1.35/m2
Packaging Details: 500 meters one roll in box
Delivery Time: 20 Working Days After Payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 150000 Square Meters Per Day
Contact Now
Detailed Product Description
Cloth Model: 6522 Fiberglass Fabric Weight: 4oz/yd2
Thickness: 0.12mm Width: 71cm, 27.6"
Color: Transparent White Yarn Type: E-glass
Keyword: 4oz Fiberglass Fabric, Surfboard Fiberglass Cloth Feature: Easy Wet-Out, Fire Resistant, High Strength

Transparent White 4oz Fiberglass Fabric / 6522 Surfboard Glass Fiber Cloth



6522 is a lightweight fiberglass fabric, its weight is 120g/m2. This 0.12mm thick glass fabric is easy to wet out so it is bery suitable for surfboard/boat building application. There are two types of glass fiber fabric which are used for surfboard fibreglass cloth, E-glass and S-glass.



Lightweight cloth that is very common in small craft boat building. Wets out fairly transparent. Most used fabric in cedar strip canoe type applications. Used commonly for applications where a clear wet-out is necessary. It is tightly woven, high performance e-glass. High strength to weight ratio. Used mainly in more advanced composite laminates.



Plain weave fabrics are balanced which means they have the same amount of glass fibers running the length of the fabric as they across the fabric. Warp fabrics generally take the same amount of total glass and more in the length of the surfboard, can have a stronger board without adding more weight. The 4oz surfboard fabrics weigh the same between plain weave and warp. It is equally as easy to use. Like other plain woven, it delivers uniform strength in both horizontal and vertical directions, with warp and fill yarns at zero and 90 degrees, respectively.



It is very suitable for many industries. Now it can be introduced as a separately series. A series of glass fiber fabric used for sports goods, such as the snowboard, surf board and skimboard.



Data Sheet



Item Weave

Count

(Warp/Fill)

Weight Thickness

Strength

(Warp/Fill)

Width
JT8120W-12-70 Plain 24/22 120g/m2 0.12mm 170/140(lbf/in) 70cm





Features

  1. Chemical resistance
  2. Plain weave, even thickness
  3. High strength
  4. Easily impregnated with resin, high cohesive strength
  5. E-Grade fabric has excellent electricity insulation properties
  6. Uniform horizontal and vertical strength
  7. Minimize print of laminate fabrics
  8. Cures transparent
  9. Fiberglass rolls for boats
  10. Surfboard fiberglass repair



Items Weight(g/m2, oz/yd2) Thickness(mm)
106 24.4/0.72 0.033
1080 46.8/1.38 0.053
2116 103.8/3.06 0.094
7629 210/6.19 0.18
7642 227.8/6.72 0.254
1037 23/0.68 0.027
1067 30.7/0.91 0.035
7637 228/6.73 0.224



Pictures









E-glass fabrics are produced in standard or warp enhanced constructions. It is balanced and wets out well for typical glassing applications. E glass surfboard cloth is produced with treatment to meet the special requiements of the surfboard industry.



Surfboars made of high strength “S” glass fabrics are used by competitive riders for its added strength, durability and light weight properties.
